Rated voltage	12VDC
Number of Pole	4
Speed Variation Ratio	1/64
Stride Angle	5.625o /64
DC resistance	2007%(25)
Idle In-traction Frequency	>600Hz
Idle Out-traction Frequency	>1000Hz
In-traction Torque	>39.2mN.m(120Hz)
Self-positioning Tor	>34.3mN.m
insulated resistance	>10M(500V)
insulated electricity power	600VAC/1mA/1s
Insulation grade	A
Rise in Temperature	<35K(120Hz)
Noise	<35dB(100Hz,No load,10cm)
Weight	About 40g

application scope: Mainly used in wind guiding board of fission air conditioner in house, wind heating board etc
